Tractor Trailer Quick Release Valve Manufacturers

European Quick Release Valve – Precision Exhaust for Faster Brake Release

Zhejiang Gongzheng Machinery Co., Ltd. is a professional European Quick Release Valve manufacturer and supplier, serving the global commercial vehicle industry with air brake components designed for European-standard trucks, tractors, and trailers. Our quick release valves are engineered to rapidly exhaust brake chamber pressure when the brake pedal is released, ensuring responsive brake disengagement and reducing lining drag. We supply a range of configurations to match OE port layouts, mounting brackets, and flow requirements for both on-road and off-road applications.

As a China-based factory with a 30,000 m² facility and over 200 employees, we integrate R&D, die-casting, assembly, and 100% functional testing under one roof. Our European quick release valves are part of a broader pneumatic control portfolio that includes relay valves, trailer valves, ABS/EBS modulators, and air dryers, allowing us to support complete air system projects.

Available Range – European Quick Release Valve Variants

We offer multiple quick release valve models to match different vehicle platforms and system architectures. Each variant is designed for direct replacement or new assembly integration.

Application Fit and Process Considerations

European quick release valves are installed between the brake chamber and the control valve (foot brake or relay valve). Their primary function is to vent brake chamber pressure directly to atmosphere when the control pressure drops, bypassing the longer return path through the control valve. This reduces brake release time and improves lining life.

We match the valve variant to the vehicle’s air system architecture:

• Tractor front/rear axles: Standard or low-noise variant for cab comfort.
• Trailer systems: Compact or universal M22 variant for cross-brand compatibility.
• Cold/wet environments: Anti-condensation variant with integrated drain.
• EBS-equipped vehicles: Electronically piloted variant for precise pressure management.

Critical Specifications and Performance

Each quick release valve is designed to meet the following performance criteria relevant to European commercial vehicle standards:

• Operating pressure: 8–12 bar (typical system pressure).
• Flow capacity: Sufficient to exhaust a standard brake chamber (e.g., type 20/24) within 0.4 seconds at 8 bar.
• Port threads: M22×1.5, NPT, or custom as specified.
• Body material: Aluminum alloy or zinc die-cast with corrosion-resistant coating.
• Seals: NBR or EPDM, rated for -40°C to +100°C.
• Leakage: Internal and external leakage tested to less than 10 cm³/min at 8 bar.

Configuration and Customization

We support both standard catalog models and custom configurations. For OEM or large-volume projects, we can adjust port orientation, mounting bracket geometry, thread type, and pilot pressure range. Our R&D team works from your sample or 3D model to produce a tailored design. Over 70% of components are manufactured in-house, giving us control over lead time and quality.

Quality Assurance and Testing

Our quality management system is certified to IATF 16949, and our production processes are monitored through statistical process control. Every quick release valve undergoes:

• 100% functional test (opening/closing pressure, flow, leakage).
• 100% pressure decay leak test.
• Sample-based durability cycling (1 million cycles minimum).
• Salt spray corrosion resistance per ISO 9227 (72–240 hours depending on specification).

Information We Use to Configure Your Solution

To prepare an accurate quotation and select the correct quick release valve, we need the following project information:

Installation, Maintenance, and Service

Our quick release valves are designed for straightforward installation using standard pneumatic fittings. No special tools are required. For maintenance, we recommend periodic inspection of seal condition and port thread integrity. Replacement seals and service kits are available for high-volume users. We maintain a standing inventory of over 200,000 units across our product range, enabling rapid fulfillment of both standard and urgent orders.

Frequently Asked Questions
